Product features
ZS-1200 automatic grooving machine(manual feeding) is used for making V grooves on industrial paperboard, grey board, MDF board, etc.
1.Energy saving: the total power is 1.5KW only, greatly reduce production cost;
2.Environment friendly: no noise and dust during production, the scraps can be recycled.
3.High efficiency: automatic cardboard feeding, greatly increase production efficiency.
4.Good finish: V groove is smooth and without burr.
Product application
Widely used in gift box, moon cake box, mobile phone box, shoes box, watch box, jewelry box, cosmetic box, tea box, wine box, medicine box, etc.
Jewelry box
Shoe box
Wine box
Gift box
Product parameters
| Model | ZS-1200 |
Cardboard width | 100-1000mm |
Cardboard length | no limit |
Cardboard thickness | 0.7-5mm |
Distance of each groove | 0-850mm |
Grooving degree | 70-140adjustable |
Max. numbers of groove | 8 |
Production speed | 10-35m/min |
Power supply | 220V/50Hz |
Total power | 1.5KW |
Machine weight | 1200kg |
Machine dimension | 1300*1310*1400mm |
