Product features
ZS-6418E automatic feeding & gluing machine is part of the automatic rigid box making machine, can collocate with automatic(semi-automatic) taping machine, automatic positioning machine, automatic(semi-automatic) forming machine, etc.
1.New model feeder automatic feeding paper, with stable performance.
2.Hot melt glue automatic circulating, mixing and gluing system.
3.Vacuum pump under conveying belt to suck the glued paper, avoid deviation.
4.Automatic fault detect and alarm.
Product application
Gift box, moon cake box, mobile phone box, shoebox, watches, jewelry boxes, cosmetic boxes, tea boxes, wine boxes, medicine packaging box, etc.
Hardcover book
Note book
File folder
Desk calendar
Moon cake box
Product parameters
| Model | ZS-6418E | |
Paper size | A min | 95mm |
| A max | 610mm | |
| B min | 180mm | |
| B max | 920mm | |
| T | 80-300g/m2 | |
Production speed | ≤40pcs/min | |
Air pressure | 0.4-0.6Mpa | |
Power supply | 380V/50Hz 3phases | |
Total power | 3.5kw | |
Machine weight | 1000kg | |
Conveyor height | 1080mm | |
Machine dimension | L6600×W1270×H1600mm | |
